Q.26 The science that deals with the occurrence, circulation and distribution of water of the earth and the earth’s atmosphere is known as __________.

1. hydraulics
2. hydrology
3. environment
4. oceanography

Correct Option: 2

Q.27 The constituents of paint in suspension are held by which vehicle that also help in its evenly distribution?

1. Plaster of Paris
2. Binder
3. Pigments
4. Base

Correct Option: 2

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.28 The type of pile foundation that is installed in soft strata to build a stable foundation for heavy structures by the method of resistance is called:

1. friction piles
2. screw piles
3. tension piles
4. end bearing piles

Correct Option: 4

Q.29 Consider the following statements regarding horizontal equivalent and contour interval.i. Horizontal equivalent between two contour lines is always constant.ii. Horizontal equivalent may be zero for a vertical cliff.iii. Contour interval should be inversely proportional to the scale.iv. For detailed design work, large contour interval is taken.Which of the given statements are correct?

1. ii and iii
2. ii and iv
3. i and iii
4. i and iv

Correct Option: 1

Q.30 In soil mechanics, what is Darcy constant?

1. coefficient of compressibility
2. coefficient of liquefaction
3. coefficient of compaction
4. coefficient of permeability

Correct Option: 4

Q.31 Which of the following methods can be used to lower the water table by using gravity flow?

1. Dewatering
2. Dehydration
3. Well point system
4. Water suction method

Correct Option: 3

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.32 Which material is used for shuttering equipment, that require very little maintenance and can be used for years?

1. Epoxy ply
2. Timber
3. Steel
4. Pressed board

Correct Option: 3

Q.33 The quantity of water in a reservoir, which cannot be utilised under normal operating conditions and is stored below the minimum pool level, is known as _____________.

1. surcharge storage
2. dead storage
3. valley storage
4. live storage

Correct Option: 2

Q.34 Traffic engineering does NOT include which of the following?i. Geometric designii. Traffic studies and analysisiii. Road user characteristicsiv. Marshall mix design

1. Only iii
2. Only i
3. Both i and iv
4. Only iv

Correct Option: 4

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

1

Q.36 Salvage value is the ___________ of an asset after all depreciation has been fully expensed.

1. scrap value
2. market value
3. book value
4. depreciation

Correct Option: 3

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.38 In the case of a _________, the brickwork is not measured in cubic metres.

1. brickwork in arches
2. reinforced brickwork
3. one and more than one brick wall
4. half-brick wall

Correct Option: 4

Q.39 Soil with particle size less than ______ mm is called fine grained soil (silt or clay).

1. 0.015
2. 0.075
3. 14.750
4. 0.020

Correct Option: 2

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.40 As per IS 2386 (1963), the aggregate crushing value is calculated by using a single sized aggregate, which is:

1. passing 40 mm and retained on 20 mm sieve
2. passing 20 mm and retained on 10 mm sieve
3. passing 12.5 mm and retained on 10 mmsieve
4. passing 4.75 mm and retained on 2.36 mm sieve

Correct Option: 3

Q.41 A road pavement should have which of the following qualities?

1. Yielding
2. Non yielding
3. Undulation
4. Deflection

Correct Option: 2

Q.42 The coefficient of discharge (Cd) in terms of the coefficient of velocity (CV) and the coefficient of contraction (CC) is:

1. Cd = CC/CV
2. Cd = CV × CC
3. Cd = CV/CC
4. Cd = CV + CC

Correct Option: 2

Q.43 Identify water-borne diseases from the following.I. TyphoidII. HepatitisIII. Malaria

1. Only I
2. Only II and III
3. Only I and II
4. Only I and III

Correct Option: 3

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.44 Pot and Bow Sleepers are which of the following type of sleepers?

1. Chock sleepers
2. Steel sleepers
3. Concrete sleepers
4. Cast iron sleepers

Correct Option: 4

Q.45 Which of the following methods of quarrying is suitable for costly, soft and stratified rocks such as sandstone, limestone, laterite, marble and slate?

1. Heating
2. Excavating
3. Blasting
4. Wedging

Correct Option: 4

Q.46 Level surface in terms of leveling is a ______.

1. datum surface
2. vertical surface
3. horizontal surface
4. curved surface

Correct Option: 4

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.47 Select the correct option for the given statements.Statement 1: Runoff is a function of precipitation, intensity, duration and its coverage.Statement 2: The size of catchment has a definite effect on the runoff. More the area, lesser will be the runoff.

1. Statement 1 is true and statement 2 is false
2. Statement 1 is false and statement 2 is true
3. Both statement 1 and statement 2 are false
4. Both statement 1 and statement 2 are true

Correct Option: 1

Q.48 Silt ejector is provided _____________.

1. in the river adjacent to the head regulator
2. in the river far off from the weir on the upstream side
3. in the canal on the downstream of head regulator
4. in the river on the downstream of the weir

Correct Option: 3

Q.49 As per IS 486:2000, in reinforced and plain concrete footings, the thickness at the edge of the footing shall not be less than ________ for footings on soils.

1. 120 mm
2. 125 mm
3. 100 mm
4. 150 mm

Correct Option: 4

SSC JE 10 Oct 2023 PAPER I Civil Shift 2 Part 6

Q.50 As per IS 2470 codes, which of the following should be the minimum width of a septic tank for five users?

1. 85 cm
2. 60 cm
3. 75 cm
4. 55 cm

Correct Option: 3
